WoodMaxx WM-8H PTO Hydraulic Wood Chipper
- USA and International Patents Pending
- Strength in design, CNC plasma cut plate steel
- 19 hp. min. required
- 3 pt. hitch mount- fits category 1 or category 2
- 8” x 8” In-Feed opening
- 200 lb. 24” Diameter Flywheel (dynamically balanced)
- 2-Reversible Made in the USA fly wheel knives, 1 bed knife (anvil)
- 1200 RPM Flywheel speed
- Hydraulic powered in-feed system w/dual counter rotating motors
- Self-contained hydraulic system (no hydraulics required from tractor)
- Variable in-feed speed 0-75 ft. /min.
- Nylon protected hydraulic hose wrap
- JIC standard hose fittings
- Hardened 6.25” dia. chisel type in-feed roller
- Quick hitch compatible (category 1 quick hitch only)
- 360 Degree swivel discharge chute
- Adjustable base legs w/ skid shoe type base
- Automatic hydro pump belt tensioner
- High flow chamber ventilation
- 2” diameter main shaft
- 3-Heavy duty cast steel main shaft bearings
- Adjustable in-feed roller down pressure
- Weight 990 lbs. (shipping)
- 8mm think steel fly wheel housing
- Easy access fly wheel knife panel
- Adjustable bed knife (to achieve proper knife gap)
- 5 Heavy duty cogged drive belts
- Safety stop bar w/reverse
- Horizontal “table height” in-feed hopper for easy loading
- Baked on powder coat finish
- Clear vinyl chip baffle
- PTO shaft included (shear bolt protected)
- Colors available; Yellow, Orange, or Green/Yellow combination.
- 3 yr. parts warranty
- 90% assembled upon delivery
- FREE shipping USA & Canada (lower 48 only, AK and HI extra)
- Experience (thousands of WoodMaxx™ machines around the world)
- Please read below for expanded descriptions of the features.
- USA and International Patents Pending
- Strength in design, CNC plasma cut plate steel
- 19 hp. min. required
- 3 pt. hitch mount- fits category 1 or category 2
- 8” x 8” In-Feed opening
- 200 lb. 24” Diameter Flywheel (dynamically balanced)
- 2-Reversible Made in the USA fly wheel knives, 1 bed knife (anvil)
- 1200 RPM Flywheel speed
- Mechanical gear driven in-feed system
- In-feed rate 50 ft. /min.
- Hardened 6.25” dia. chisel type in-feed roller
- Quick hitch compatible (category 1 quick hitch only)
- 360 Degree swivel discharge chute
- Adjustable base legs w/ skid shoe type base
- High flow chamber ventilation
- 2” diameter main shaft
- 3-Heavy duty cast steel main shaft bearings
- Adjustable in-feed roller down pressure
- Weight 950 lbs. (shipping)
- 8mm think steel fly wheel housing
- Easy access fly wheel knife panel
- Adjustable bed knife (to achieve proper knife gap)
- 5 Heavy duty cogged drive belts
- Safety stop bar
- Horizontal “table height” in-feed hopper for easy loading
- Baked on powder coat finish
- Clear vinyl chip baffle
- PTO shaft included (shear bolt protected)
- Colors available; Red, Orange
- 3 yr. parts warranty
- 90% assembled upon delivery
- FREE shipping USA & Canada (lower 48 only, AK and HI extra)
- Experience
- Please read below for expanded descriptions of the features.
- USA and International Patents Pending
- Strength in design, CNC laser cut plate steel
- 15 hp. min. required
- 3 pt. hitch mount- fits category 1 or category 2
- 100% assembled upon delivery
- Fold up in-feed bin for storage
- 8” x 6” In-Feed opening
- 120 lb. 24” Diameter Flywheel (dynamically balanced)
- 4-Reversible CR-12 High carbon steel fly wheel knives, 1 bed knife (anvil)
- 540 RPM Flywheel speed (direct drive)
- Hydraulic powered in-feed system
- Self-contained hydraulic system (no hydraulics required from tractor)
- Variable in-feed speed 0-75 ft. /min.
- Nylon protected hydraulic hose wrap
- JIC standard hose fittings
- Hardened 6.25” dia. chisel type in-feed roller
- Quick hitch compatible (category 1 quick hitch only)
- Adjustable bed knife (to achieve proper knife gap)
- 360 Degree swivel discharge chute
- High flow chamber ventilation
- 1-5/8” diameter main shaft
- 2-Heavy duty cast steel main shaft bearings
- Adjustable in-feed roller down pressure
- Weight 595 lbs. (uncrated)
- 5.5mm think steel fly wheel housing
- Easy fly wheel access (opens like a clam shell)
- Safety stop bar w/reverse
- 40 degree sloped in-feed hopper
- Baked on powder coat finish
- Clear vinyl chip baffle
- PTO shaft included (shear bolt protected)
- Colors available; Orange, Green, Yellow, Red
- 3 yr. parts warranty
- FREE shipping USA & Canada (lower 48 only, AK and HI extra)
- Experience (thousands of WoodMaxx™ machines around the world)
- 8x8 OPENING
- FEED RATE OF 36 FEET PER MINUTE
- TOTAL WEIGHT IS 725LBS.
- QUICK HITCH READY
- FLYWHEEL WEIGHS 185LBS.
- REVERSIBLE KNIVES
- ADJUSTABLE BED BLADE
- OVERALL ASSEMBLY SIZE: 36” WIDE x 84” LONG x 68” HIGH
- 360 DEGREE SWIVEL DISCHARGE CHUTE
- MEDIUM DUTY GREASABLE BEARINGS
- CLEAR VINYL BAFFLE IN IN-FEED BIN TO PROTECT USER FROM CHIP BLOW-BACK
- SAFETY BAR - TO DISENGAGE FEED ROLLER
- PTO SHAFT INCLUDED (SHEAR BOLT PROTECTED)
